VS-1680
24 bit Digital Studio Workstation
Tracks
Tracks: 16
V-Tracks: 256 (16 V-Tracks per each Track)
* Up to 8 tracks can be recorded simultaneously, and up to
16 tracks can be played back simultaneously.
Maximum Useful Capacity
128 G bytes:
2 G bytes (capacity)x 8 (Partition) x 8 (Disk Drive)
Internal Memory
Songs: 200 (each partition)
Equalizer
HI, MID, LOW (16 channels)
HI, LOW (26 channels)
Recording Mode
Multitrack Pro (MTP)
Mastering (MAS)
Multitrack 1 (MT1)
Multitrack 2 (MT2)
Live 1 (LIV1)
Live 2 (LIV2)
Signal Processing
AD Conversion: 20 bits, 64 times oversampling
DA Conversion: 20 bits, 128 times oversampling
Internal Processing: 24 bits (mixer section)
Sample Rate
48.0 kHz, 44.1 kHz, 32.0 kHz
* Sample rate can be adjusted around 22.00–50.48 kHz
(maximum) by using vari-pitch function.
Frequency Response
Sample Rate
48.0 kHz:
20 Hz–22 kHz (+0.2 dB/-0.2 dB)
44.1 kHz: 20 Hz–20 kHz (+0.2 dB/-0.2 dB)
32.0 kHz: 20 Hz–14 kHz (+0.2 dB/-0.2 dB)
Total Harmonic Distortion (INPUT
SENS: 0 dBu, 1 kHz at nominal output
level)
0.005 % or less (recording mode: MTP)
Recording Time (at 2 G bytes, 1 track)
Recording Sample Rate
Mode 48.0 kHz 44.1 kHz 32.0 kHz
MTP 742 min. 808 min. 1114 min.
MAS 370 min. 404 min. 556 min.
MT1 742 min. 808 min. 1114 min.
MT2 990 min. 1078 min. 1484 min.
LIV1 1188 min. 1292 min. 1782 min.
LIV2 1484 min. 1616 min. 2228 min.
* The above-listed recording times are approximate. Times
may be slightly depending on the specifications of the disk
drive and on the number of songs that were created.
Nominal Input Level (variable)
Input1–2: -50– +4 dBu
maximum +26 dBu:Balanced,
maximum +20 dBu:Unbalanced
Input3–8: -50– +4 dBu
maximum +26 dBu:Balanced,
maximum +20 dBu:Unbalanced
Guitar (Hi-Z): -50– +4 dBu
maximum +26 dBu:Balanced,
maximum +20 dBu:Unbalanced
Input Impedance
Input1–2: 30 k ohms
Input3–8: 30 k ohms
Guitar (Hi-Z): 500 k ohms
Nominal Output Level
Master Out: 0 dBu
AUX A (L, R): 0 dBu
AUX B (L, R):
0 dBu
Monitor Out: 0 dBu
Output Impedance
Master Out: 1 k ohm
AUX A (L, R): 1 k ohm
AUX B (L, R):
1 k ohm
Monitor Out: 1 k ohm
Headphones: 22 ohms
Specifications
66
