Iso (3-band Isolator) (p. 126)
Sw Off, On
AntiPhase LoLev 0–100
AntiPhase MidLev 0–100
LoMixSw Off, On
MidMixSw Off, On
LowLvl -60–+4 dB
MidLvl -60–+4 dB
HiLvl -60–+4 dB
VS8F-2 Algorithm List
108
3BndIsolater (3-band Isolator)
The input sound is separated into three frequency ranges — high, mid, and low — each of
which can be boost or cut.
fig.ap(efx)-63(iso_blk.eps)
3 Band
Isolater L
3 Band
Isolater R
Input L
Input R
Output L
Output R
TapeEcho201 (Tape Echo 201)
This is a tape echo which simulates the Roland RE-201.
fig.ap(efx)-65(echo_blk.eps)
TapeEcho201
Input L
Input R
Output L
Output R
Echo (Tape Echo 201) (p. 126)
Sw Off, On
Mode 1–7
Repeat Rate 0–100
Intnsty 0–100
Tone Bass -100–100
Tone Treble -100–100
Pan HeadS L63–R63
Pan HeadM L63–R63
Pan HeadL L63–R63
Tape Dist 0–100
WahFlutter Rate 0–100
WahFlutter Depth 0–100
EfxLvl 0–100
DirLvl 0–100
