Flg (Flanger) (p. 115)
Sw Off, On
Pol Inv, Sync
Rate 0.1–10.0 Hz
Depth 0–100
Manual
0–100
Reso 0–100
CrossFBLvl 0–100
EfxLvl -100–100
DirLvl -100–100
EQ (Equalizer) (p. 110)
Sw Off, On
Low Gain -12–12 dB
Low Freq 20–2000 Hz
Low Q 0.3–10.0
Low Type Shlv, Peak
Mid Gain -12–12 dB
Mid Freq 200–8000 Hz
Mid Q 0.3–10.0
High Gain -12–12 dB
High Freq 1.4–20.0 kHz
High Q 0.3–10.0
Hi Type Shlv, Peak
Level 0–100
VS8F-2 Algorithm List
94
St Flanger (Stereo Flanger)
This algorithm is a stereo flanger. A three-band equalizer is provided on the output.
fig.ap(efx)-33(stfl_blk.eps)
Input L
Input R
Output L
Output R
Flanger L
Flanger R
Equalizer
Equalizer
