(HOST) <= F0 41 10 00 0E 12 03 01 00 aa aa aa aa ss F7 <= (VS-1680)
aaaaaaaa = time of Marker #3
If the mark point is less than 3, the VS-1680 does not return the block of “aaaaaaaa”.
Example 4) Read all mark points ( DeviceID = 10 )
(HOST) => F0 41 10 00 0E 12 03 01 00 7F 7F 7F 7F 7A F7
=> (VS-1680)
7F7F7F7F(>= 1000) means All marker
(HOST) => F0 41 10 00 0E 12 03 01 04 00 76 F7 => (VS-1680)
(HOST) <= F0 41 10 00 0E 12 03 01 00 nn nn nn nn ss F7 <= (VS-1680)
nnnnnnnn = total marker number, ss = check sum
(HOST) <= F0 41 10 00 0E 12 03 01 00 aa aa aa aa ss F7 <= (VS-1680)
aaaaaaaa = time of Marker #1
(HOST) <= F0 41 10 00 0E 12 03 01 00 bb bb bb bb ss F7 <= (VS-1680)
bbbbbbbb = time of Marker #2
:
(HOST) <= F0 41 10 00 0E 12 03 01 00 xx xx xx xx ss F7 <= (VS-1680)
xxxxxxxx = time of the last Marker#
If the mark point does not exist, the VS-1680 does not return blocks under “aaaaaaaa”.
Example 5) Delete the mark point ( DeviceID = 10 )
(HOST) => F0 41 10 00 0E 12 03 01 00 aa aa aa aa ss F7 => (VS-1680)
aaaaaaaa = time of Marker
(HOST) => F0 41 10 00 0E 12 03 01 04 02 74 F7 => (VS-1680)
(HOST) <= F0 41 10 00 0E 12 03 01 00 nn nn nn nn ss F7 <= (VS-1680)
nnnn = total marker number, ss = check sum
The VS-1680 deletes the mark point which includes specified time, and returns the
total numbers of the mark points.
(*4) Write Locate data into a bank memory (Set Locate Bank), and read from a bank memo-
ry (Get Locate Bank), according to the Locate Bank number (0-3) set in Marker Number.
● Effect parameters
✧ Basic Address
+—————————————————————————————————————————————————————————————————+
| Start | |
| address | Contents and remarks |
|==========+=========+============================================|
| 04 00 00 | 0aaaaaaa| Effector - 1 Algorithm aaaaaaabbbbbbb =|
| 04 00 01#| 0bbbbbbb| ( 0:Reverb *1) |
| | | 1:Delay |
| | | 2:Stereo Delay Chorus |
| | | 3:Stereo Pitch Shifter Delay |
| | | 4:Vocoder |
| | | 5:2ch RSS |
| | | 6:Delay RSS |
| | | 7:Chorus RSS |
| | | 8:Guitar Multi 1 |
| | | 9:Guitar Multi 2 |
| | | 10:Guitar Multi 3 |
| | | 11:Vocal Multi |
| | | 12:Rotary |
| | | 13:Guitar Amp Simulator |
| | | 14:Stereo Phaser |
| | | 15:Stereo Flanger |
| | | 16:Dual Comp/Limiter |
| | | (17:Gate Reverb *1) |
| | | 18:Multi Tap Delay |
| | | 19:Stereo Multi |
| | | 20:Reverb 2 |
| | | 21:Space Chorus |
| | | 22:Lo-Fi Processor |
| | | 23:4Band Parametric Equalizer |
| | | 24:10Band Graphic Equalizer |
| | | 25:Hum Canceler |
| | | 26:Vocal Canceler |
| | | (27:Voice Transfomer *1,*2) |
| | | (28:Vocoder 2 *1,*2) |
| | | 29:Mic Simulater |
| | | 30:3Band Isolator |
| | | 31:Tape Echo 201 |
| | | 32:Analog Flanger |
| | | 33:Analog Phaser |
|——————————+—————————+————————————————————————————————————————————|
| 04 00 02 | 20 - 7E | Effector - 1 Name -1 (ASCII) |
| : | : | : |
| 04 00 0D | 20 - 7E | Effector - 1 Name -12 |
|——————————+—————————+————————————————————————————————————————————|
| 04 00 0E | 00 - 7F | Effector - 1 Parameter Area (See Below) |
| : | : | : |
| 04 00 7F | 00 - 7F | |
|——————————+—————————+————————————————————————————————————————————|
| 04 01 00 | 0aaaaaaa| Effector - 2 Algorithm aaaaaaabbbbbbb =|
| 04 01 01#| 0bbbbbbb| ( 0:Reverb *1) |
| | | 1:Delay |
| | | 2:Stereo Delay Chorus |
| | | 3:Stereo Pitch Shifter Delay |
| | | 4:Vocoder |
| | | 5:2ch RSS |
| | | 6:Delay RSS |
| | | 7:Chorus RSS |
| | | 8:Guitar Multi 1 |
| | | 9:Guitar Multi 2 |
| | | 10:Guitar Multi 3 |
| | | 11:Vocal Multi |
| | | 12:Rotary |
| | | 13:Guitar Amp Simulator |
| | | 14:Stereo Phaser |
| | | 15:Stereo Flanger |
| | | 16:Dual Comp/Limiter |
| | | (17:Gate Reverb *1) |
| | | 18:Multi Tap Delay |
| | | 19:Stereo Multi |
| | | 20:Reverb 2 |
| | | 21:Space Chorus |
| | | 22:Lo-Fi Processor |
| | | 23:4Band Parametric Equalizer |
| | | 24:10Band Graphic Equalizer |
| | | 25:Hum Canceler |
| | | 26:Vocal Canceler |
| | | (27:Voice Transfomer *1,*2) |
| | | (28:Vocoder 2 *1,*2) |
| | | 29:Mic Simulater |
| | | 30:3Band Isolator |
| | | 31:Tape Echo 201 |
| | | 32:Analog Flanger |
| | | 33:Analog Phaser |
|——————————+—————————+————————————————————————————————————————————|
| 04 01 02 | 20 - 7E | Effector - 2 Name -1 (ASCII) |
| : | : | : |
| 04 01 0D | 20 - 7E | Effector - 2 Name -12 |
|——————————+—————————+————————————————————————————————————————————|
| 04 01 0E | 20 - 7E | Effector - 2 Parameter Area (See Below) |
| : | : | : |
| 04 01 7F | 20 - 7E | |
|——————————+—————————+————————————————————————————————————————————|
| 04 02 00 | 0aaaaaaa| Effector - 3 Algorithm aaaaaaabbbbbbb =|
| 04 02 01#| 0bbbbbbb| ( 0:Reverb *1) |
| | | 1:Delay |
| | | 2:Stereo Delay Chorus |
| | | 3:Stereo Pitch Shifter Delay |
| | | 4:Vocoder |
| | | 5:2ch RSS |
| | | 6:Delay RSS |
| | | 7:Chorus RSS |
| | | 8:Guitar Multi 1 |
| | | 9:Guitar Multi 2 |
| | | 10:Guitar Multi 3 |
| | | 11:Vocal Multi |
| | | 12:Rotary |
| | | 13:Guitar Amp Simulator |
| | | 14:Stereo Phaser |
| | | 15:Stereo Flanger |
| | | 16:Dual Comp/Limiter |
| | | (17:Gate Reverb *1) |
| | | 18:Multi Tap Delay |
| | | 19:Stereo Multi |
| | | 20:Reverb 2 |
| | | 21:Space Chorus |
| | | 22:Lo-Fi Processor |
| | | 23:4Band Parametric Equalizer |
| | | 24:10Band Graphic Equalizer |
| | | 25:Hum Canceler |
| | | 26:Vocal Canceler |
| | | (27:Voice Transfomer *1,*2) |
| | | (28:Vocoder 2 *1,*2) |
| | | 29:Mic Simulater |
| | | 30:3Band Isolator |
| | | 31:Tape Echo 201 |
| | | 32:Analog Flanger |
| | | 33:Analog Phaser |
|——————————+—————————+————————————————————————————————————————————|
| 04 02 02 | 20 - 7E | Effector - 3 Name -1 (ASCII) |
| : | : | : |
| 04 02 0D | 20 - 7E | Effector - 3 Name -12 |
|——————————+—————————+————————————————————————————————————————————|
| 04 02 0E | 20 - 7E | Effector - 3 Parameter Area (See Below) |
| : | : | |
| 04 02 7F | 20 - 7E | |
|——————————+—————————+————————————————————————————————————————————|
| 04 03 00 | 0aaaaaaa| Effector - 4 Algorithm aaaaaaabbbbbbb =|
| 04 03 01#| 0bbbbbbb| ( 0:Reverb *1) |
| | | 1:Delay |
| | | 2:Stereo Delay Chorus |
| | | 3:Stereo Pitch Shifter Delay |
| | | 4:Vocoder |
| | | 5:2ch RSS |
| | | 6:Delay RSS |
| | | 7:Chorus RSS |
| | | 8:Guitar Multi 1 |
| | | 9:Guitar Multi 2 |
| | | 10:Guitar Multi 3 |
| | | 11:Vocal Multi |
| | | 12:Rotary |
| | | 13:Guitar Amp Simulator |
| | | 14:Stereo Phaser |
| | | 15:Stereo Flanger |
| | | 16:Dual Comp/Limiter |
| | | (17:Gate Reverb *1) |
| | | 18:Multi Tap Delay |
| | | 19:Stereo Multi |
| | | 20:Reverb 2 |
| | | 21:Space Chorus |
| | | 22:Lo-Fi Processor |
| | | 23:4Band Parametric Equalizer |
| | | 24:10Band Graphic Equalizer |
| | | 25:Hum Canceler |
| | | 26:Vocal Canceler |
| | | (27:Voice Transfomer *1,*2) |
| | | (28:Vocoder 2 *1,*2) |
| | | 29:Mic Simulater |
| | | 30:3Band Isolator |
| | | 31:Tape Echo 201 |
| | | 32:Analog Flanger |
| | | 33:Analog Phaser |
|——————————+—————————+————————————————————————————————————————————|
| 04 03 02 | 20 - 7E | Effector - 4 Name -1 (ASCII) |
| : | : | : |
| 04 03 0D | 20 - 7E | Effector - 4 Name -12 |
MIDI Implementation
43
