Getting Ready

Setting up the pedalboard

Set up the pedalboard as shown below.

For the PK-25A

Position the pedalboard so that the lower

keyboard’s A4 key is aligned with the

center of the PK-25A’s expression pedal.

Position the pedalboard so that the

ATELIER’s rear panel is aligned with the

PK-25A’s rear panel.

For the PK-7A

Position the pedalboard so that the lower

keyboard’s C5 key is aligned with the

center of the PK-7A’s expression pedal.

Position the pedalboard so that the

ATELIER’s rear panel is aligned with the

PK-7A’s rear panel.
