#Dly Bal (Delay balance ) D> 0E - D 0
Adjust the volume balance between the direct and
the delay sound.
“
D
” or “
E
” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Dly Pan (Delay Output Pan) L63 - 0 - R63 [18]
Adjust the stereo position of the delay sound. L63 is
far left, 0 is center, and R63 is far right.
Dly Level (Delay Level) 0 - 127 [19]
Adjust the volume of the delay sound.
Level (Output level ) 0 - 127 [20]
Adjust the output level.
58: Cho / Flanger (Chorus / Flanger) [11H, 02H]
This effect connects a chorus and a flanger in parallel.
Cho Dly (Chorus pre delay ) 0 - 100m [1]
Adjust the time delay from when the direct sound
begins until the chorus sound is heard.
Cho Rate (Chorus rate ) 0.05 - 10.0 [2]
Adjust the modulation speed of the chorus effect.
Cho Depth (Chorus depth ) 0 - 127 [3]
Adjust the modulation depth of the chorus effect.
+Cho Bal (Chorus balance ) D> 0E - D 0
Adjust the volume balance between the direct and
the chorus sound.
“
D
” or “
E
” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Cho Pan (Chorus Output Pan) L63 - 0 - R63 [16]
Adjust the stereo position of the chorus sound. L63
is far left, 0 is center, and R63 is far right.
Cho Level (Chorus Level) 0 - 127 [17]
Adjust the volume of the chorus sound.
FL Dly (Flanger pre delay ) 0 - 100m [6]
Adjust the time delay from when the direct sound
begins until the flanger sound is heard.
FL Rate (Flanger rate ) 0.05 - 10.0 [7]
Adjust the modulation speed of the flanger effect.
FL Depth (Flanger depth ) 0 - 127 [8]
Adjust the modulation depth of the flanger effect.
FL Fb (Flanger feedback level ) -98% - +98% [9]
Adjust the proportion (%) of the flanger sound that
is fed back into the effect. Negative (-) settings will
invert the phase.
#FL Bal (Flanger balance ) D> 0E - D 0
Adjust the volume balance between the direct and
the flanger sound.
“
D
” or “
E
” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
FL Pan (Flanger Output Pan) L63 - 0 - R63 [18]
Adjust the stereo position of the flanger sound. L63
is far left, 0 is center, and R63 is far right.
FL Level (Flanger Level) 0 - 127 [19]
Adjust the volume of the flanger sound.
Level (Output level ) 0 - 127 [20]
Adjust the output level.
59: OD1 / OD2 (Overdrive / Distortion1,2)|
[11H, 03H]
This connects two effect units in parallel, each of
which allows you to select Overdrive or Distortion.
OD1 Sel (OD1 Select) Odrv/Dist [1]
Select either Overdrive or Distortion for set 1.
+OD1 Drive (OD1 Drive) 0 - 127 [2]
Adjust the depth of distortion for set 1. The volume
will change together with the depth of distortion.
OD1 Amp (OD1 Amp Simulator Type)
Small/BltIn/2-Stk/3-Stk [3]
Select the type of guitar amp for set 1.
Small : small amp
BltIn : single-unit type amp
2-Stk : large double stack amp
3-Stk : large triple stack amp
L
R
Chorus
Flanger
Balance
Pan
Pan
L
R
Overdrive/
Distortion 2
Overdrive/
Distortion 1
Pan
Pan
Chapter 4. Insertion Effects 86
