Fb Mode is Norm:
Fb Mode is Cross:
Dly Tm L (Delay time left) 0 - 500m [1]
Adjust the time from the original sound until when
the left delay sound is heard.
Dly Tm R (Delay time right) 0 - 500m [2]
Adjust the time from the original sound until when
the right delay sound is heard.
+Feedback (Feedback level) -98% - +98% [3]
Adjust the proportion (%) of the processed sound
that is fed back into the effect. Negative (-) settings
will invert the phase.
Fb Mode (Feedback mode) Norm/Cross [4]
Select the way in which processed sound is fed
back into the effect.
Norm : The left delay sound will be fed back
into the left delay, and the right delay
sound into the right delay.
Cross : The left delay sound will be fed back
into the right delay, and the right
delay sound into the left delay.
Phase L (Phase left) Norm/Invert [5]
Select the phase of the left delay sound.
Norm : Phase will not be changed.
Invert : Phase will be inverted.
Phase R (Phase right) Norm/Invert [6]
Select the phase of the right delay sound.
Norm : Phase will not be changed.
Invert : Phase will be inverted.
HF Damp 315 - 8k/Bypass [8]
Adjust the frequency above which sound fed back
to the effect will be cut. If you do not want to cut the
high frequencies of the feedback, set this parameter
to Bypass.
#Balance (Effect balance) D> 0E - D 0
Adjust the volume balance between the direct and
the processed sound.
“
D
” or “
E
” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Low Gain -12 - +12 [17]
Adjust the gain of the low frequency range.
Hi Gain (High gain) -12 - +12 [18]
Adjust the gain of the high frequency range.
Level (Output level) 0 - 127 [20]
Adjust the output level.
22: Mod Delay (Modulation Delay) [01H, 51H]
This effect adds modulation to the delayed sound, pro-
ducing an effect similar to a flanger.
Fb Mode is Norm:
Fb Mode is Cross:
Dly Tm L (Delay time left) 0 - 500m [1]
Adjust the time from the original sound until when
the left delay sound is heard.
Dly Tm R (Delay time right) 0 - 500m [2]
Adjust the time from the original sound until when
the right delay sound is heard.
Feedback (Feedback level) -98% - +98% [3]
Adjust the proportion (%) of the processed sound
that is fed back into the effect. Negative (-) settings
will invert the phase.
Fb Mode (Feedback mode) Norm/Cross [4]
Select the way in which processed sound is fed
back into the effect.
Norm : The left delay sound will be fed back
into the left delay, and the right delay
sound into the right delay.
Cross : The left delay sound will be fed back
into the right delay, and the right
delay sound into the left delay.
+Mod Rate (Modulation rate) 0.05 - 10.0 [5]
Adjust the speed of the modulation.
Mod Depth (Modulation depth) 0 - 127 [6]
Adjust the depth of the modulation.
Mod Phase (Modulation phase) 0 - 180 [7]
Adjust the spatial spread of the sound.
L
R
Delay
Delay
HF
HF
EQ
EQ
Balance
Balance
L
R
Delay
Delay
HF
HF
EQ
EQ
Balance
Balance
L
R
Delay
Delay
HF
HF
EQ
EQ
Balance
Balance
L
R
Delay
Delay
HF
HF
EQ
EQ
Balance
Balance
Chapter 4. Insertion Effects 65
