Chapter 8. Appendix 149
■ Computer cable wiring diagrams
6 7 8
3 4 5
1 2
6 7 8
3 4 5
1 2
6 7 8
3 4 5
1 2
mini DIN, 8-pin, male mini DIN, 8-pin, male
mini DIN, 8-pin, male
D-sub, 25-pin, female
mini DIN, 8-pin, male mini DIN, 8-pin, male
1 HSKo
2 HSKi
3 TXD-
4 GND
5 RXD-
6 TXD+
7 GPi
8 RXD+ HSKo 1
HSKi 2
TXD- 3
GND 4
RXD- 5
TXD+ 6
GPi 7
RXD+ 8
6 7 8
3 4 5
1 2
mini DIN, 8-pin, male
D-sub, 9-pin, female
mini DIN, 8-pin, male D-sub, 9-pin, female
HSKo 1
HSKi 2
TXD- 3
GND 4
RXD- 5 7 RTS
8 CTS
3 TXD
5 GND
2 RXD
5 1
9 6
13 1
25 14
For Apple Macintosh (Sold separately: RSC-15APL)
For IBM PC/AT (9-pin) (Sold separately: RSC-15AT)
For IBM PC/AT (25-pin)
mini DIN, 8-pin, male D-sub, 25-pin, female
HSKo 1
HSKi 2
TXD- 3
GND 4
RXD- 5 4 RTS
5 CTS
2 TXD
7 GND
3 RXD
