Roland SC-88 Pro - Manual (Page 46)

● Using Chorus and Delay
In the case of a Drum Instrument, it is not possible to simultaneously use both chorus
and delay. Chorus will not be applied to a Drum Instrument for which “ d ” and “ D ” is dis-
played in the CHORUS column (Fig.2). In this case, you can apply chorus by using the
CHORUS [ l ] [ r ] buttons to set the chorus send level.
Delay will not be applied to a Drum Instrument for which a number is displayed in the
CHORUS column (Fig.1). In this case, you can apply delay by press the EFX TYPE [ l ]
[ r ] buttons to set the delay send level. In other words, in the case of chorus and delay,
only the one you specify last will be valid.
* The Delay setting will be displayed as “ d00 ” — “ d99 ” for values of 0 to 99, and as “ D00 ” —
“ D27 ” for values of 100 to 127.
● About the Assign Group
Each instrument can be given a number, and instruments with the identical number
are treated as an Assign Group. No two instruments of the same Assign Group will
sound together. If while one instrument is sounding, a MIDI message is received to play
another instrument in the same Assign Group, the first instrument will be turned off first.
This is a useful way to prevent two instruments from sounding simultaneously that would
not normally do so. For example since it is obviously impossible for a hi-hat to simulta-
neously produce both an open hi-hat sound and a closed hi-hat sound, these two
sounds could be set to the same Assign Group (the same number) so that they would
not sound together.
Numbers from Non, 1 to 127 can be selected, but instruments for which Non is
selected will not be turned off by other instruments. In other words, instruments with a
setting of Non will not be treated as an Assign Group.
* Be aware that if you select a different Drum Set, the parameter values will be initialized.
PART INSTRUMENT
PART
AD1
127
116
62
20
R18
Non
REVERB CHORUS
LEVEL PAN
MIDI CH
001 C3 Hi.Tom 2
K SHIFT
DELAY
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
PART INSTRUMENT
PART
AD1
127
116
62
d20
R18
Non
REVERB CHORUS
LEVEL PAN
MIDI CH
001 C3 Hi.Tom 2
K SHIFT
DELAY
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
CHORUS
/DELAY column
Drum edit screen
Fig.1
Fig.2
Chapter 2. Parts and paramters 44
