Effect list – Roland SC-88 Pro User Manual
Page 178
Chapter 8. Appendix
176
Parameter
Value (Dec.)
Value (Hex.) min - max MSB/LSB(H)
0 : Thru
00
00
❍
Effects that modify the tone color (filter type)
1 : Stereo-EQ
01
00
Low Freq
200/400
00/01
03
Low Gain
-12 - +5 - +12
34 - 4C
04
Hi Freq
4k/8k
00/01
05
Hi Gain
-12 - +12
34 - 4C
06
M1 Freq
200 - 1.6k - 6.3k
*10
07
M1 Q
0.5/1.0/2.0/4.0/9.0
00/01/02/03/04
08
M1 Gain
-12 - +8 - +12
34 - 4C
09
M2 Freq
200 - 1k - 6.3k
*10
0A
M2 Q
0.5/1.0/2.0/4.0/9.0
00/01/02/03/04
0B
M2 Gain
-12 - -8 - +12
34 - 4C
0C
+ Level
0 - 127
00 - 7F
16
2 : Spectrum
01
01
Band 1
-12 - -4 - +12
34 - 4C
03
Band 2
-12 - +1 - +12
34 - 4C
04
Band 3
-12 - +3 - +12
34 - 4C
05
Band 4
-12 - +6 - +12
34 - 4C
06
Band 5
-12 - +2 - +12
34 - 4C
07
Band 6
-12 - -1 - +12
34 - 4C
08
Band 7
-12 - -4 - +12
34 - 4C
09
Band 8
-12 - -5 - +12
34 - 4C
0A
Width
0.5/1.0/2.0/4.0/9.0
00/01/02/03/04
0B
+ Pan
L63 - 0 - R63
00 - 7F
15
# Level
0 - 127
00 - 7F
16
3 : Enhancer
01
02
+ Sens
0 - 64 - 127
00 - 7F
03
# Mix
0 - 127
00 - 7F
04
Low Gain
-12 - +3 - +12
34 - 4C
13
Hi Gain
-12 - 0 - +12
34 - 4C
14
Level
0 - 127
00 - 7F
16
4 : Humanizer
01
03
Drive
0 - 48 - 127
00 - 7F
03
Drive Sw
Off/On
00/01
04
+ Vowel
a/i/u/e/o
00/01/02/03/04
05
Accel
0 - 15
*14
06
Low Gain
-12 - 0 - +12
34 - 4C
13
Hi Gain
-12 - 0 - +12
34 - 4C
14
Pan
L63 - 0 - R63
00 - 7F
15
# Level
0 - 127
00 - 7F
16
❍
Effects that distort the sound (distortion type)
5 : Overdrive
01
10
+ Drive
0 - 48 - 127
00 - 7F
03
Amp Type
Small/BltIn/2-Stk/3-Stk
00/01/02/03
04
Amp Sw
Off/On
00/01
05
Low Gain
-12 - 0 - +12
34 - 4C
13
Hi Gain
-12 - 0 - +12
34 - 4C
14
# Pan
L63 - 0 - R63
00 - 7F
15
Level
0 - 96 - 127
00 - 7F
16
6 : Distortion
01
11
+ Drive
0 - 76 - 127
00 - 7F
03
Amp Type
Small/BltIn/2-Stk/3-Stk
00/01/02/03
04
Amp Sw
Off/On
00/01
05
Low Gain
-12 - 0 - +12
34 - 4C
13
Hi Gain
-12 - -8 - +12
34 - 4C
14
# Pan
L63 - 0 - R63
00 - 7F
15
Level
0 - 84 - 127
00 - 7F
16
❍
Effects that modulate the sound (modulation type)
Parameter
Value (Dec.)
Value (Hex.) min - max MSB/LSB(H)
7 : Phaser
01
20
+ Manual
100 - 620 - 8k
*12
03
# Rate
0.05 - 0.85 - 10.0
*6
04
Depth
0 - 64 - 127
00 - 7F
05
Reso
0 - 16 - 127
00 - 7F
06
Mix
0 - 127
00 - 7F
07
Low Gain
-12 - 0 - +12
34 - 4C
13
Hi Gain
-12 - 0 - +12
34 - 4C
14
Level
0 - 104 - 127
00 - 7F
16
8 : Auto Wah
01
21
Fil Type
LPF/BPF
00/01
03
Sens
0 - 127
00 - 7F
04
+ Manual
0 - 68 - 127
00 - 7F
05
Peak
0 - 62 - 127
00 - 7F
06
# Rate
0.05 - 2.05 - 10.0
*6
07
Depth
0 - 72 - 127
00 - 7F
08
Polarity
Down/Up
00/01
09
Low Gain
-12 - 0 - +12
34 - 4C
13
Hi Gain
-12 - 0 - +12
34 - 4C
14
Pan
L63 - 0 - R63
00 - 7F
15
Level
0 - 96 - 127
00 - 7F
16
9 : Rotary
01
22
Low Slow
0.05 - 0.35 - 10.0
*6
03
Low Fast
0.05 - 6.40 - 10.0
*6
04
Low Accl
0 - 3 - 15
*14
05
Low Level
0 - 127
00 - 7F
06
Hi Slow
0.05 - 0.90 - 10.0
*6
07
Hi Fast
0.05 - 7.50 - 10.0
*6
08
Hi Accl
0 - 11 - 15
*14
09
Hi Level
0 - 64 - 127
00 - 7F
0A
Separate
0 - 96 - 127
00 - 7F
0B
+ Speed
Slow/Fast
00/7F
0D
Low Gain
-12 - 0 - +12
34 - 4C
13
Hi Gain
-12 - 0 - +12
34 - 4C
14
# Level
0 - 127
00 - 7F
16
10 : Stereo Flanger
01
23
Pre Filter
Off/LPF/HPF
00/01/02
03
Cutoff
250 - 8k
*9
04
Pre Dly
0 - 1.6m - 100m
*1
05
+ Rate
0.05 - 0.60 - 10.0
*6
06
Depth
0 - 24 - 127
00 - 7F
07
# Feedback
-98% - +80% - +98%
0F - 71
08
Phase
0 - 180
00 - 5A
09
Balance
D> 0E - D=E - D 0 00 - 7F 12 Low Gain -12 - 0 - +12 34 - 4C 13 Hi Gain -12 - 0 - +12 34 - 4C 14 Level 0 - 104 - 127 00 - 7F 16 11 : Step Flanger 01 24 Pre Dly 0 - 1.0m - 100m *1 03 Rate 0.05 - 0.30 - 10.0 *6 04 Depth 0 - 95 - 127 00 - 7F 05 + Feedback -98% - +30% - +98% 0F - 71 06 Phase 0 - 180 00 - 5A 07 # Step Rate 0.05 - 2.75 - 10.0 *6 08 Balance D> 0E - D=E - D 0 00 - 7F 12 Low Gain -12 - 0 - +12 34 - 4C 13 Hi Gain -12 - 0 - +12 34 - 4C 14 Level 0 - 96 - 127 00 - 7F 16 ■ Effect list +: Effect control 1 can be used to modify the value (p.92) For Effect Type (data section) The correspondence between setting values and hexadeci- Pre Delay Time *8 HF Damp *2 Delay Time 1 *9 Cutoff Freq *3 Delay Time 2 *10 EQ Freq *4 Delay Time 3 *11 LPF *5 Delay Time 4 *12 Manual *6 Rate 1 *13 Azimuth *7 Rate 2 *14 Accl
#: Effect control 2 can be used to modify the value (p.92)
MSB/LSB: Indicates the ** portion of the following exclusive mes-
sages. (p.196) (hexadecimal notation)
F0 41 dev 42 12 40 03 00 ** ** sum F7
For Effect Parameters (LSB part of address)
F0 41 dev 42 12 40 03 ** data sum F7
(dev: device ID, sum: checksum)
mal values for items in the Value column indicated with "*" is
shown in the "Effect Data Table" (p. 183).
*1
