Chapter 4 Parameters
NI-FBUS Configurator User Manual 4-30 ni.com
SHED_OPT (Mode Shedding, Option)
Controls the way blocks enter mode shedding. Each option listed below has
a companion
No Return option. The No Return shedding options change
the target mode of the device to the shed mode and prevent the device from
re-entering
RCas or ROut mode after the shed condition has ended.
SHED_RCAS (Mode Shedding)
The shed time for the RCAS_IN parameter. If the block is in RCas mode and
the RCAS_IN parameter has not been updated in SHED_RCAS time, the
block performs mode shedding as determined by the SHED_OPT parameter.
SHED_ROUT (Mode Shedding)
The shed time for the ROUT_IN parameter. If the block is in RCas mode and
the ROUT_IN parameter has not been updated in SHED_RCAS time, the
block performs mode shedding as determined by the SHED_OPT parameter.
SIMULATE (Option)
Used to bypass the physical I/O channel and allow the block to operate
normally, using a simulated I/O channel.
Note For this feature to be enabled on an FP-3000, you must set a switch on the back of
the device. To see how to configure the switch, refer to the FP-3000 manual.
SIMULATE_D (Option)
Used to bypass the physical I/O channel and allow the block to operate
normally, using a simulated discrete I/O channel.
Table 4-21. Shed Conditions
Shed Mode Behavior
Normal Shed The block sheds into the next higher-priority mode set in the permitted
mode field of
MODE_BLK .
Shed to Auto The block sheds into automatic mode.
Shed to Manual The block sheds into manual mode.
Shed to Retained The block sheds to the next higher priority mode set in the target mode
field of
MODE_BLK .
