Marking Events
9-2 Storing, Retrieving & Printing
Marking Events
The button allows you to annotate the ECG strip at the point in time the
button is pressed. In AED Mode, when monitoring is disabled, the event is
marked with a . In Manual Mode, or when monitoring is enabled in AED
Mode, you use the softkeys to select the annotation from the choices dis-
played (See Figure 9-1)*. If no selection is made, the event is marked with a
.
Figure 9-1 Annotations
NOTE *In Australia and the U.K.,
(3, is replaced by $'51 (adrenaline).
The marked event is stored in the Event Summary. If the printer is configured
to
3ULQW RQ 0DUN, an ECG strip prints when
is pressed. If the printer is
configured to
VHFRQG GHOD\, the strip is 9 seconds and includes 6 seconds pre-
ceding the event and 3 seconds following the event. If
1R 'HOD\ is configured, a
3 second ECG strip prints in real time. To stop printing before the entire strip
is printed, press
.
Mark
Event
EPI ATRO LIDO OTHER
Pads
Shocks:0
00:00:8
72
CHARGE ENERGY
SELECT
150 J
Mark
Event
Print
Strip
