Philips HEARTSTART XLT M3500B User Manual
Page 87
Pacing
M3500B HeartStart XLT Defibrillator/Monitor
8-5
8
4. Adjust the rate to the desired number of paced pulses per minute (ppm).
Press up,
, or down,
, on
to increase or decrease the num-
ber of paced pulses per minute.
5. Press
to start pacing.
The message
3DFLQJ indicates that paced pulses are being delivered in the
selected mode at the rate and output level displayed.
Figure 8-2: Pacing Display
NOTE
Pacing will not start if there is a problem with the multifunction defib elec-
trode pads connections or, in demand mode, a problem with the ECG monitor-
ing electrodes connections. Should a problem exist, a system message is
displayed. Be attentive to system messages.
Rate
Start
Stop
ENERGY
SELECT
HR ALARM
LEAD
SELECT
CHARGE
Shocks:0
00:00:8
78
SpO2
150 J
Pacing
Demand Mode
70ppm 30mA
Lead II
