Operational Checks
11-4 Maintaining the HeartStart XLT
Shift/System Check
To perform the Shift/System Check:
1. Turn the HeartStart XLT off.
2. Connect a 50 ohm test load to the pads patient cable (instead of pads).
3. If a Data Card is routinely used, insert a Data Card into the HeartStart
XLT.
4. If a power module is used, unplug the power module.
5. Insert a charged battery.
6. While pressing , press On to start the test.
7. Follow the prompts on the display to proceed with the test. If the message
6HUYLFH 8QLW appears, check the information in Table 12-2 and Table 12-3 .
If the message continues to appear, do not use the device, and call for
service.
The test takes less than a minute to complete. When it is done, a report is
printed, as shown in Figure 11-1. Test results are listed as Pass or Fail, with
the exception of the Data Card Test. For the Data Card Test, the results indi-
cate either the amount of storage time remaining on the data card or that no
data card is present.
Figure 11-1 Shift/System Check Report
Print
Strip
Shift/System Check 8 Jan 1999 13:52:17 SN:US00000001
Current Tests:
General System Test Pass
ECG Test Pass
Backup Power Test Pass
SpO2 Test: Pass
Data Card Test 2:00
Defib Test Pass
Pacer Test Pass
Qty/Check List:
___ Defibrillator Inspection
___ Cables/Connectors
___ Defibrillation Pads
___ Monitoring Electrodes
___ Charged Batteries
___ AC/DC Power Module
___ Printer Paper
___ Data Card
___ Ancillary Supplies
___ SpO2 Sensor
