Disabling the HR Alarm
M3500B HeartStart XLT Defibrillator/Monitor 4-7
4
Disabling the HR Alarm
If the heart rate is outside the HR alarm limits, an alarm sounds. To disable the
alarm, press . appears to indicate that the alarm is disabled.
Adjusting the ECG Size
To increase or decrease the size of the ECG, press or on the gain con-
trol, .
Troubleshooting
Table 4-5 provides troubleshooting tips for ECG Monitoring.
+5 $/$50
Table 4-5 Troubleshooting Tips
Situation Cause Solution
/HDGV 2II
message
or
dashed line (------)
z The monitoring elec-
trodes are not applied
or are not making
proper contact with the
patient.
z The monitoring cable is
not connected.
z Check that the monitoring
electrodes are properly
applied.
z Check that the monitoring
cable is properly con-
nected.
3DGV 2II
message z The pads are not mak-
ing proper contact with
the patient. z Check that the pads are
properly applied.
