Defibrillating
3-8 Defibrillating in AED Mode
2. If instructed, press .
If device-initiated analysis is off, the HeartStart XLT monitors the rhythm
(provided Rhythm Monitoring is on) and prompts you to press
if
a potentially shockable rhythm is detected.
Figure 3-5 Press ANALYZE Display
NOTE If monitoring capabilities are enabled on your HeartStart XLT, your display
will contain monitoring information not shown in the graphics in this section.
NOTE ECG Analysis is always performed through multifunction defib electrode
pads. Analysis can not be performed through monitoring electrodes.
$1$/<=(
$1$/<=(
Shocks: 0
00:00:04
Check Patient
If No Pulse
Press ANALYZE
PAUSE
ANALYZE
