Page 22
Getting Acquainted
2-2
Getting Started
Basic Orientation
The figure below shows the general layout of the controls, where the patient
cables connect, and where to insert the battery and Data Card.
Figure 2-1 Basic Orientation
Audiovisual
Controls
ECG
Connector
SpO
2
Connector
Manual Mode
Controls
Battery
Ambient Light
Sensor
Pads
Connector
Off
On
Printer
Print Controls
Monitoring Controls
AC Power
Module Connector
Data Card
Defibrillation
Controls
Speaker
