VOR/ILS Analyzer EVS200
0796.1800.02 E-8 0.1
Contents
Contents
Chapter Page
1. Operator Information
- Important operator information 1
- Unpacking 2
- Application of the unit 3
- Characteristics of the unit 4
- Unit layout frontview 5
- Unit layout rearview 6
2. Preparation for Operation
- Placing the unit 7
- Mains operation 7
- Mains connection 7
- DC connection 8
- Assembling the FO Cable Jack 8
- Finishing and connection to the Vehicle Board Supply 8
- Connection of Signal/Control Inputs/Outputs 9
- Antenna connection 9
- AF OUT 9
- RS-232-Interface 9
- External AF input 10
- DSP output 10
3. Operation
- Switch On/switch Off the unit at mains supply 11
- Switch On/switch Off the unit at VDC supply 11
- Switch on procedure 11
- Selftest (BITE) 12
- Battery operation 12
- Operation of the unit 13
- General operating instructions of the VOR/ILS Analyzer EVS200 13
- SETUP-Mode 14
- Operating instructions of SETUP-Mode 15
