6 E-8
Chapter 1: Operator Information
Unit layout rearview
external VDC input
When an external VDC supply is connected
the installed battery (option) is switched off.
U
9 to 15 VDC
I 2 A
input
max
antenna input
not applicable (optional)
DSP output
The scaling of the XY values can be set
in the setup / Y / t setup (ILS mode) for
the
and mode.
BNC socket
localizer glideslope
mains switch
Master switch only
for mains operation
on/off
mains fuses
F1 / F2
IEC127-T800H / 250 V
mains connector
socket
87 to 265 VAC
47 to 63 Hz
SUB-D socket:
COM parameter:
BAUD rate: 9pole
N81
1200, 2400,
4800, 9600,
19200 adjustable in
the setup
RS-232-Interface
external AF input
The external AF input is to select
in the setup.
BNC socket
input level:
1 to 2 V / 50
rms
Ω
VOR/ILS Analyzer EVS200
0796.1800.02
