Signal parameters on VOR display
Following signal parameters are indicated on the display:
display indication
description
measuring value
FREQ. (MHZ)
receiver frequency in MHz (numerical) and
bargraph center frequency indication in kHz
MHz
LEVEL (dBm)
receiver signal in dBm (numerical) and
bargraph indication (the lower bargraph
shows the set squelch threshold)
dBm
DISPL 1/2
BEARING
BEARING angle
DEG
AM-MOD.(30HZ)
AM modulation depth (30 Hz)
%
AM-MOD.(9960HZ)
AM modulation depth (9960 Hz)
%
FM-DEVIATION
frequency deviation
Hz
FM-INDEX
FM index value
index value
(non-dimension value)
DISPL 2/2
ID AF-FREQ.
AF frequency (1020 Hz)
Hz
ID AM-MOD.
AM modulation depth of AF frequency
%
VOICE AM-MOD.
AM modulation depth in the range of
300 to 3000 Hz
%
