VOR/ILS Analyzer EVS200
0796.1800.02 E-8 45
Chapter 3: Operation
Command FM0
command function
FM0 FM-deviation query
The command FM0 reads the actual FM-deviation value in the VOR mode.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: FM0
fm0 e.g. 479.1Hz
e.g. 479.1Hz
Command FM1
command function
FM1 query of FM-index value
The command FM1 reads the actual FM-index value in the VOR mode.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: FM1
fm1 e.g. 15.9
e.g. 15.9
Command D1
command function
D1 switching over to Display1
The command D1 enables the switching over to the content of display1 in the VOR / ILS mode.
This is the prediction for reading out the data of the corresponding mode (VOR/ILS).
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
input: D1
d1 READY
READY
