VOR/ILS Analyzer EVS200
0796.1800.02 E-8 50
Chapter 3: Operation
Beacon-Mode
Command AM4
command function
AM4 query of AM-modulation depth (F1)
The command AM4 reads the actual AM-modulation depth (F1 3000 Hz) in the BEACON mode.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: AM4
am4 e.g. 29.3%
e.g. 29.3%
Command AM5
command function
AM5 query of AM-modulation depth (F2)
The command AM5 reads the actual AM-modulation depth (F2 1300 Hz) in the BEACON mode.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: AM5
am5 e.g. 30.5%
e.g. 30.5%
Command AM6
command function
AM6 query of AM-modulation depth (F3)
The command AM6 reads the actual AM-modulation depth (F3 400 Hz) in the BEACON mode.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: AM6
am6 e.g. 29.8%
e.g. 29.8%
