VOR/ILS Analyzer EVS200
0796.1800.02
E-8
33
Chapter 3: Operation
Command RES
command
function
RES
Master-RESET
With the command RES a unit master reset is possible. It works like a restart of the unit.
Example:
command from the controller
response of the VOR/ILS Analyzer EVS200
input:
RES
res
READY
READY
EVS200 REMOTE-SYSTEM READY
Command BI
command
function
BI
BITE (Build In Test) -asking for result
The EVS200 performs approx. every 500 ms a self test (BITE) and makes the result available as a
9bit binary form. During this test the following voltages and funtionally subunits of the units are
checked.
all operating voltages,
hostprocessor
memory,
DSP-processor,
battery capacity (%)
explanation of BITE information
B8
B7
B6
B5
B4
B3
B2
B1
B0
SYNTH 1
SYNTH 2
EXT-DC
PS-DC
+12 VDC
-12 VDC
Batt2
Batt1
Batt0
X
X
X
X
X
X
X
X
X
X = 1
is function in tolerance (ok)
X = 0
is function out of tolerance (failure)
Example:
command from the controller
response of the VOR/ILS Analyzer EVS200
query:
BI
BI110111101
