VOR/ILS Analyzer EVS200
0796.1800.02
E-8
37
Chapter 3: Operation
Command AM2
command
function
AM2
query of AM modulation depth (90 Hz)
The command AM2 reads the actual AM modulation depth (90 Hz) in the ILS mode.
Example:
command from the controller
response of the VOR/ILS Analyzer EVS200
query:
AM2
am2
e.g.
50%
e.g.
50%
Command AM3
command
function
AM3
query of AM modulation depth (150 Hz)
The command AM3 reads the actual AM modulation depth (150 Hz) in the ILS mode.
Example:
command from the controller
response of the VOR/ILS Analyzer EVS200
Query:
AM3
am3
e.g.
29.9%
e.g.
29.9%
Command PH
command
function
PH
query of Phase angle 90/150 Hz
The command PH reads the actual PHI value between 90 Hz and 150 Hz in the ILS mode.
Example:
command from the controller
response of the VOR/ILS Analyzer EVS200
query:
PH
ph
e.g.
119.9DEG
e.g.
119.9DEG
