VOR/ILS Analyzer EVS200
0796.1800.02 E-8 43
Chapter 3: Operation
Command AF8
command function
AF8 AF-frequency ID query
The command AF8 reads the actual AF frequency (ID) in the ILS /VOR mode.
Prediction for reading out the data of the corresponding mode (VOR/ILS) is the
switching over to display2.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: AF8
af8 e.g. 1020.0Hz
e.g.. 1020.0Hz
Command AM8
command function
AM8 query of AM-modulation depth (ID)
The command AM8 reads the actual AM-modulation depth (ID) in the ILS / VOR mode.
Prediction for reading out the data of the corresponding mode (VOR/ILS) is the
switching over to display2.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: AM8
am8 e.g. 10.0%
e.g. 10.0%
Command AM9
command function
AM9 query of AM-modulation depth (voice)
The command AM9 reads the actual AM-modulation depth (voice 300 Hz to 3kHz) in the ILS / VOR
mode.
Prediction for reading out the data of the corresponding mode (VOR/ILS) is the
switching over to display2.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: AM9
am9 e.g. 09.6%
e.g. 09.6%
