Procom VOR/ILS Analyzer EVS200 - Manual (Page 41)

VOR/ILS Analyzer EVS200
0796.1800.02 E-8 32
Chapter 3: Operation
Command EC1
command function
EC1 selection of communication
EVS200 retransmits the received control string.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: EC1
ec1 READY
READY
Command test
command function
TEST < > RS232 test section output
The command TEST initiates a RS232 test section. All ASCII characters 20h to FF will be supplied.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: EC1
ec1 READY
READY
Command LA
command function
LA query of receiving level
The command LA reads the actual receiving signal level in "
∆∆∆∆
Level"-mode.
Example:
command from the controller response of the VOR/ILS Analyzer EVS200
query: LA
la e.g. -48.1dBm
e.g. -48.1dBm
