Chapter 3: Operation
Signal parameters on BEACON display
Following signal parameters are indicated on the display:
display indication
description
measuring value
FREQ. (MHZ)
receiver frequency in MHz (numerical) and
bargraph center frequency indication in kHz
MHz
LEVEL (dBm)
receiver signal in dBm (numerical) and
bargraph indication (the lower bargraph
shows the set squelch threshold)
dBm
F1
AF frequency and AM modulation depth at
3000 Hz (inner marker)
Hz and %
F2
AF frequency and AM modulation depth at
1300 Hz (middle marker)
Hz and %
F3
AF frequency and AM modulation depth at
400 Hz (outer marker)
Hz and %
ID
AF frequency and AM modulation depth of
the identifier
Hz and %
