VOR/ILS Analyzer EVS200
0796.1800.02 E-8 57
Chapter 6: Technical Specification
Glideslope mode
Measurement error at
30 to 50% modulation..........................
≤ ±
0.0008 DDM
±
0.1% of reading
Resolution (LOC / GS) ........................ 0.0001 DDM
DSP out
Localizer: Range 1 .......................... 0.0
±
25%
0
±
0.25 DDM
Range 2 0.0
±
2.5%
0
±
0.025 DDM
Range 3 .......................... 0.0
±
2.58%
0.0
±
0.0258 DDM
Range 4 .......................... 0.0
±
50%
0.0
±
0.5 DDM
Glideslope: Range 1 .......................... 0.0
±
50%
0.0
±
0.5 DDM
Range 2 .......................... 0.0
±
5%
0.0
±
0.05 DDM
Range 3 .......................... 8.75
±
5%
0.0875
±
0.05 DDM
Range 4 .......................... 17.5 +5%
0.175 +0.05 DDM
SDM measurement
SDM 10 to 80% ................................ accuracy 1% absolute
Resolution ................................ 0.0001 SDM
VOR signal analysis
Bearing
Accuracy ........................................
±
0.1°
Resolution ........................................0.05° / 0.01° (Setup)
AM modulation depth
30 Hz and 9,96 kHz
Accuracy ........................................
≤
1%
Resolution ........................................0.1%
FM deviation
Accuracy ........................................0.5%,
±
0.1 Hz
Resolution ........................................0.1 Hz
RS-232-Interface ........................................8N1, adjustable baud rate
1200, 2400, 4800, 9600, 19200
