VOR/ILS Analyzer EVS200
0796.1800.02 E-8 28
Chapter 3: Operation
Signal parameters on
∆∆∆∆
Level Display
Following signal parameters are indicated on the display::
display indication description measuring value
FREQ. (MHZ) receiver frequency in MHz (numerical) and
bargraph center frequency indication in kHz MHz
LEVEL (dBm) receiver signal in dBm (numerical) and
bargraph indication (the lower bargraph
shows the set squelch threshold) dBm
∆
LEVEL (dB) actual
∆
level (difference between actual
receiving level and set reference level)
the bargraph indication shows the
∆
level
as a tendency indication
dB
LEVEL REF. set reference level dBm
