Installing, Adapter, Riser-card – Lenovo 3797 User Manual
Page 62: Assembly
3.
Press
down
on
the
left
and
right
side
latches
and
slide
the
server
out
of
the
rack
enclosure
until
both
slide
rails
lock;
then,
remove
the
cover
(see
4.
Remove
the
PCI
riser-card
assembly
that
contains
the
adapter
(see
v
If
you
are
removing
an
adapter
from
PCI
expansion
slot
1
or
2,
remove
PCI
riser-card
assembly
1.
v
If
you
are
removing
an
adapter
from
PCI
expansion
slot
3
or
4,
remove
PCI
riser-card
assembly
2.
5.
Disconnect
any
cables
from
the
adapter
(make
note
of
the
cable
routing,
in
case
you
reinstall
the
adapter
later).
6.
Carefully
grasp
the
adapter
by
its
top
edge
or
upper
corners,
and
pull
the
adapter
from
the
PCI
expansion
slot.
7.
If
the
adapter
is
a
full-length
adapter
in
the
upper
expansion
slot
of
the
PCI
riser-card
assembly
and
you
do
not
intend
to
replace
it
with
another
full-length
adapter,
remove
the
full-length-adapter
bracket
and
store
it
on
the
underside
of
the
top
of
the
PCI
riser-card
assembly.
8.
If
you
are
instructed
to
return
the
adapter,
follow
all
packaging
instructions,
and
use
any
packaging
materials
for
shipping
that
are
supplied
to
you.
Installing
a
PCI
adapter
in
a
PCI
riser-card
assembly
To
ensure
that
a
ServeRAID-10i,
ServeRAID-10is,
or
ServeRAID-10M
adapter
works
correctly
in
your
server,
make
sure
that
the
adapter
firmware
is
at
the
latest
level.
Important:
Some
cluster
solutions
require
specific
code
levels
or
coordinated
code
updates.
If
the
device
is
part
of
a
cluster
solution,
verify
that
the
latest
level
of
code
is
supported
for
the
cluster
solution
before
you
update
the
code.
Some
high
end
video
adapters
are
supported
by
your
server.
See
for
more
information.
Notes:
1.
If
you
are
installing
a
video
adapter
in
your
server,
do
not
set
the
maximum
digital
video
resolution
above
1600
x
1200
at
60
Hz
for
an
LCD
monitor.
This
is
the
highest
resolution
supported
for
any
video
adapter
in
this
server.
2.
Any
high-definition
video-out
connector
or
stereo
connector
on
the
video
adapter
is
not
supported.
These
instructions
apply
to
PCI
adapters
such
as
video
graphics
adapters
and
network
adapters.
To
install
a
SAS
controller,
go
to
46
ThinkServer
RD220
Types
3729,
3779,
3797,
and
3798:
Installation
and
User
Guide
