There

are

two

types

of

checkpoint

codes:

field

programmable

gate

array

(FPGA)

hardware

checkpoint

codes

and

UEFI

checkpoint

codes.

The

UEFI

checkpoint

codes

might

change

because

of

code

sequence

and

timing

changes

or

when

the

server

firmware

is

updated.

v

Reset

button:

Press

this

button

to

reset

the

server

and

run

the

power-on

self-test

(POST).

You

might

have

to

use

a

pen

or

the

end

of

a

straightened

paper

clip

to

press

the

button.

The

reset

button

is

in

the

lower

right-hand

corner

of

the

diagnostics

panel.

For

more

information

about

EasyLED

diagnostics,

see

the

Hardware

Maintenance

Manual.

The

following

table

lists

the

LEDs

on

the

EasyLED

diagnostics

panel

and

suggested

actions

to

solve

the

detected

problems.

v

Follow

the

suggested

actions

in

the

order

in

which

they

are

listed

in

the

Action

column

until

the

problem

is

solved.

v

See

the

parts

listing

in

the

Hardware

Maintenance

Manual

to

determine

which

components

are

customer

replaceable

units

(CRU)

and

which

components

are

field

replaceable

units

(FRU).

v

If

an

action

step

is

preceded

by

“(Trained

service

technician

only),”

that

step

must

be

performed

only

by

a

trained

service

technician.

LED

Description

Action

None,

but

the

system-
error

LED

is

lit.

An

error

has

occurred

and

cannot

be

diagnosed,

or

the

IMM

has

failed.

The

error

is

not

represented

by

an

EasyLED

diagnostics

LED.

Use

the

Setup

utility

to

check

the

system-event

log

for

information

about

the

error.

OVER

SPEC

The

server

was

shut

down

due

to

a

power-supply

overload

condition

on

one

of

the

power

channels.

The

power

supplies

are

using

more

power

than

the

maximum

rating.

1.

If

any

of

the

12v

power

channel

error

LEDs

(A,

B,

C,

D,

E,

or

AUX)

on

the

system

board

are

lit

also,

see

“Power

problems”

on

page

138.

(See

“System-board

LEDs”

on

page

27

for

the

location

of

the

power

channel

error

LEDs.)

2.

Check

the

power

supply

LEDs

for

an

error

indication

(AC

LED

and

DC

LED

are

not

both

lit,

or

the

power-supply

error

LED

is

lit).

Swap

power

supplies

1

and

2

with

each

other.

v

If

the

error

follows

the

power

supply,

replace

the

failed

power

supply.

v

If

the

error

remains

with

the

power

bay,

(trained

service

technician

only)

replace

the

system

board.

3.

Remove

optional

devices

from

the

server.

LOG

An

error

message

has

been

written

to

the

system-event

log

Check

the

IMM

system

event

log

and

the

system-error

log

for

information

about

the

error.

Replace

any

components

that

are

identified

in

the

error

logs.

LINK

Reserved.

PS

A

power

supply

has

failed.

1.

Check

the

power

supply

LEDs

for

an

error

indication

(AC

LED

and

DC

LED

are

not

both

lit).

See

Table

16

on

page

149

for

more

information.

2.

Make

sure

that

the

failing

power

supply

is

correctly

seated.

3.

Replace

the

failed

power

supply.

18

ThinkServer

RD220

Types

3729,

3779,

3797,

and

3798:

Installation

and

User

Guide
