Index
Special characters
, about 7
A
ac power LED 23
acoustical noise emissions 11
adapter
installing 46, 56
PCI bus, identification 56
removing 45, 54
requirements 56
SAS
See RAID controller
slot types 56
adapter bracket (full-length)
installing 60
storing 60
adapter bracket, storing 49
administrator password 107
Advanced Settings Utility (ASU) program,
overview 121
air baffle
DIMM
installing 53
removing 52
microprocessor 2
installing 51
removing 50
assistance, getting 151
attention notices 2
availability 12
B
battery
connector 24
replacing 97, 98
beep codes 127
blue-screen capture feature
overview 124
boot manager program
using 109
boot precedence, default 56
C
cable connectors 24
cabling
external 101
internal routing 38
system-board external connectors 25
system-board internal connectors 24
caution statements 2
CD drive
See CD-RW/DVD
CD-RW/DVD drive
installing 90
removing 89
CD/DVD drive
activity LED 15
problems 130
CD/DVD-eject button 15
checkpoint codes
on the EasyLED diagnostics panel display 18
configuration programs
LSI Configuration Utility 103
connectors
battery 24
cable 24
external port 25
fans 24
front 101
hard disk drive 28
internal 24
internal cable routing 38
memory 24
microprocessor 24
PCI 24
port 25
rear 101
SAS riser card 28
system board 24
tape drive 28
controllers
Ethernet 118
controls and LEDs
on the diagnostics panel 16
operator information panel 16
cooling 11
cover
removing 37
creating
RAID array 112
CRUs, replacing
battery 97
CD-RW/DVD drive 90
DIMMs 62
memory 62
D
danger statements 2
Diagnostics panel display
checkpoint codes 18
diagnostics program, preboot 8
DIMMs
installation sequence for memory mirroring 67
installing 69
order of installation 66
removing 62
display problems 136
documentation DVD 2
drive, installing hot-swap 88
© Lenovo 2009. Portions © IBM Corp. 2007. 165
