68
CLEANING THE MAIN CHARGER OF THE
PHOTOCONDUCTIVE DRUM
If black lines or colored lines appear even after you have cleaned the document glass and automatic document feeder,
use the charger cleaner to clean the main charger that charges the drum.
1
Open the front cover (lower).
2
Open the inner cover.
3
Clean the main charger.
(1) Slowly pull out the green knob (charger
cleaner) as far as it will go.
(2) After the green knob (charger cleaner) is
pulled out, slowly push it all the way back
in.
4
Repeat step 3 with each of the other
charger cleaners.
There are a total of 3 places to be cleaned in the machine as
shown.
5
Close the inner cover.
Charger cleaner
