Technical data of CPU 31xC

6.6 Technical data of the integrated I/O

CPU 31xC and CPU 31x, Technical data
Manual, Edition 08/2004, A5E00105475-05

6-41

Parameters of standard DO

There are no parameters for standard digital outputs.

Parameters of standard AI

The table below gives you an overview of the parameters for standard analog inputs.

Table 6-9

Parameters of standard AI

Parameters

Value range

Default

Range of efficiency

Integration time (ms)
Interference suppression

(Hz)
(channel 0 to 3)

2,5/16,6/20
400/60/50

20
50

Channel
Channel

Measurement range
(channel 0 to 3)

Disabled/

+/- 20 mA/

0 ... 20 mA/

4 ... 20 mA/

+/- 10 V/

0 ... 10 V

+/- 10 V

Channel

Type of measurement
(channel 0 to 3)

Disabled/

V voltage/

I current

U voltage

Channel

Unit of measurement
(channel 4)

Celsius/Fahrenheit/

Kelvin

Celsius

Channel

Measurement range

(Pt 100 input; channel 4)

Disabled/

Pt 100/600 Ω

600 Ω

Channel

Type of measurement

(Pt 100 input; channel 4)

Disabled/

resistor/

thermocouple

Resistance

Channel

Reference
