50 Intel® Server System SR2500AL User’s Guide
Figure 40. Removing the Slimline Optical Drive Assembly from the Server
System
7. Press downward on the side of the tray (see letter “A”) and disengage the drive
from the two metal tabs on the opposite side of the tray (see letter “B”).
8. Lift up on the optical drive (see letter “C”) to remove it from the tray.
Figure 41. Removing the Slimline Optical Drive from the Tray
AF000151
B A
C
AF000152
B
A
C
