Intel® Server System SR2500AL User’s Guide 13
The NIC LEDs at the right and left of each NIC provide the following information.
RAID Support
The server system provides an embedded SATA controller that supports both 1.5 and 3.0
Gbps data transfer rates.
The BIOS Setup utility provides multiple drive configuration options on the Advanced |
ATA Controller setup page, some of which affect the ability to configure RAID. The
“Onboard SATA Controller” option is enabled by default. When this option is enabled, the
“SATA Mode” option can be set to either Legacy or Enhanced. The Legacy and Enhanced
modes affect the RAID configuration as follows:
• Legacy supports four disk drives and does not provide RAID support.
• Enhanced supports six disk drives and is required for RAID configurations.
When the enhanced mode is selected, you can choose to enable or disable “AHCI Mode”
or “Configure SATA as RAID”. Intel ® Embedded Server RAID Technology II is enabled
by the option, “Configure SATA as RAID.” The Intel
®
Embedded Server RAID
Technology II feature provides RAID modes 0, 1, and 10.
For RAID 0, 1, and 10, enclosure management is provided through the SATA_SGPIO
connector on the server board when a cable is attached between this connector on the
server board and to the backplane or I
2
C interface.
If RAID 5 is desired, the optional Intel
®
RAID Activation Key AXXRAKSW5 can be
installed. To enable RAID 5, this activation key is placed on the SATA Key connector that
is located at the left side of the server board. For information on how to install the Intel ®
RAID Activation Key AXXRAKSW5 accessory to enable RAID 5, see the
documentation that is included with the accessory kit.
For information on configuring RAID, see the RAID software user’s guide that is
included on the Intel ® Server Deployment Toolkit 2.0 CD .
Table 3. NIC LED Descriptions
LED LED State Description
Left Off No network connection
Solid Amber Network connection in place
Blinking Amber Transmit/receive activity
Right Off 10 Mbps connection (if left LED is on or blinking)
Solid Amber 100 Mbps connection
Solid Green 1000 Mbps connection
