4 Intel® Server System SR2500AL User’s Guide
Table 2 summarizes the features of the server system.
Table 2. Intel
®
Server System SR2500ALLX and/or the Intel
®
Server System
SR2500ALBRP Feature Summary
Feature Description
Dimensions • 3.44 inches (87.30 mm) high
•
16.93 inches (430 mm) wide
• 27.75 inches (704.8 mm) deep
• 65 pounds (29.5 kg) - max chassis weight
Server Board Intel
®
Server Board S5000PAL
Processor See the Intel ® Server Board S5000PAL/S5000XAL Technical
Product Specification for information on processor support.
Memory
•
Eight DIMM slots supporting stacked DDR2 533/667 MHz
FBDIMM memory
•
Support for up to 32 GB DDR2 533/667 MHz FBDIMM memory
Chipset Intel ® 5000P chipset, consisting of:
• Intel
®
5000P Memory Controller Hub (MCH)
• Intel ® 6321ESB I/O Controller Hub
Peripheral Interfaces External connections:
• Stacked PS/2* ports for keyboard and mouse
• RJ45 Serial B port
• Two RJ45 NIC connectors for 10/100/1000 Mb connections
•
Two USB 2.0 ports
Internal connections:
• One USB port header, which supports two USB 2.0 ports
• One DH10 Serial A header
• Six Serial ATA 150 connectors with integrated RAID 0/1
support
• One ATA-100 44-pin connector for optical drive support
•
SSI-compliant 24-pin control panel header
•
SSI-compliant 24-pin main power connector, supporting the
ATX-12V standard on the first 20 pins
I/O Controll National Semiconductor* PC87427 controller
Video On-board ATI* ES1000 video controller with 16 MB DDR SDRAM
LAN Intel ® 82563EB dual port controller for 10/100/1000 Mbit/sec
Ethernet LAN connectivity
Expansion Capabilities
•
One low profile riser slot supporting 1U or 2U PCI Express*
riser cards
• One full height riser slot supporting 1U or 2U PCI-X* and PCI
Express* riser cards
