Type 9306 Model 900/910
57
Selector switch environment:
Figure 22. Single selector switch
Figure 23. Multiple selector switch
Power Distribution Unit
Note: For information and installation instructions for the IBM NetBAY Rack Power
Distribution Units, see “NetBAY Power Distribution Units” on page 141.
Monitor
Keyboard Mouse
Selector Switch
Server 1
Server 2
Server 3
Server 4
Console
Cable
Set
Monitor
Keyboard Mouse
Server 1
Server 2
Server 3
Server 4
Secondary Selector Switch
Console
Cable
Set
Primary Selector Switch
Server 5
