IBM NetBAY console switch
139
9. Connect one end of a console cable set to one of the numbered ports on the rear of
the console switch.
10. Route the console cable set toward the rear of your rack cabinet, and up or down
toward your server. Use the cable straps that come with this option to secure the
console cable set along the way.
11. Connect the other end of the console cable set to the appropriate monitor, mouse,
and keyboard connectors on your server.
12. Repeat step 9. to step 11. for all servers that you need to connect to your console
switch.
13. Connect the power cord that comes with the console switch to the power
connector on the rear of the console switch.
14. Route the power cord toward the rear of your rack cabinet, and either up or down
toward a properly wired and grounded power source such as an uninterruptable
power supply (UPS), a power distribution unit (PDU), or an electrical outlet. Use
the cable straps that come with this option to secure the power cord along the
way, and use the openings in your rack cabinet if you must exit the rack to
connect to your power source.
15. Refer to the Apex User Guide CD for configuration and operation information
about your console switch.
Parts listing (NetBAY Console Switch)
NetBAY (Console Switch) FRU
1x4 switch 06P6003
2x8 switch 06P6004
7-foot locking console cable 06P6006
12-foot locking console cable 06P6007
