Page 92: Nstallation, Figure 5-12: lcd rotate jumper location
A300 Motherboard
The LCD Rotate jumper location is shown in Figure 5-12.
Figure 5-12: LCD Rotate Jumper Location
5.6 Chassis Installation
5.6.1 Airflow
WARNING:
Airflow is critical to the cooling of the CPU and other onboard
components. The chassis in which the A300 must have air vents to
allow cool air to move into the system and hot air to move out.
The A300 must be installed in a chassis with ventilation holes on the sides allowing airflow
to travel through the heat sink surface. In a system with an individual power supply unit,
Page 77
