B.1 GPIO Settings and Default Values
B.1.1 GPIO Settings
Two addresses (320h and 321h) on the LVC chipset are reserved to control the GPIO
connector.
Port 320h stores the data that is inputted to or outputted from the specified pin
on the GPIO connector.
Port 321h is the input/output setting register for each pin on the GPIO
connector. If a pin outputs data, the corresponding bit is set to “0.” If a pin
inputs data, the corresponding bit is set to “1.” The table below outlines the
status of each GPIO pin.
GPIO N Status
Bit Number
Corresponding GPIO pin
Bit N = 0
Bit N = 1
Bit 0
GPIO 0
Output
Input
Bit 1
GPIO 1
Output
Input
Bit 2
GPIO 2
Output
Input
Bit 3
GPIO 3
Output
Input
Bit 4
GPIO 4
Output
Input
Bit 5
GPIO 5
Output
Input
Bit 6
GPIO 6
Output
Input
Bit 7
GPIO 7
Output
Input
B.1.2 Default Settings
The default settings for all the bits (Bit 0 to Bit 7) for both Port 320h and Port 321h are 00h.
Bit Number
Port 320h
Port 321h
Bit 0
00h
00h
Bit 1
00h
00h
Bit 2
00h
00h
Bit 3
00h
00h
