Page 81
A300 Motherboard
See Figure 5-2.
Step 0:
Figure 5-2: Lock the CPU Socket Retention Screw
5.3.2 Cooling Kit CF-479B-RS Installation
Figure 5-3: IEI CF-518-RS and CF-479A-RS Cooling Kit
An IEI Socket 479 CPU cooling kit can be purchased separately. See Figure 5-3. The
cooling kit comprises a CPU heat sink and a cooling fan.
