5 lcd rotation jumper, Figure 5-11: lcd voltage selection jumper location, Table 5-6: lcd rotate jumper settings – Intel iEi Motherboard A300 User Manual
Page 91: See figure 5-11, Figure 5-11
A300 Motherboard
Figure 5-11: LCD Voltage Selection Jumper Location
5.5.5 LCD Rotation Jumper
Jumper Label:
CN16
Jumper Type:
2-pin header
Jumper Settings:
Jumper Location:
Use the LCD Rotate jumper to rotate the LCD. The LCD Rotate settings are shown in
LCD Rotate
Description
1
LCD Rotate
2
GND
Table 5-6: LCD Rotate Jumper Settings
Page 76
