A300 Motherboard

17 N/C

42 IORDY

18 SA2

43 SDREQ

19 SA1

44 SDACK#

20 SA0

45 HDD_ACTIVE#

21 DATA

0 46 66DET

22 DATA

1 47 DATA

8

23 DATA

2 48 DATA

9

24 N/C

49 DATA

10

25 VCC-IN

CHECK2

50 GROUND

Table 4-5: CF Card Socket Pinouts

4.2.4 Fan Connectors

CN Label:

CPU_FAN1, SYS_FAN1 and SYS_FAN2

CN Type:

3-pin wafer connector

CN Location:

See Figure 4-6

CN Pinouts:

See Table 4-6

The cooling fan connectors on the A300 provide a 12V, 500mA current to a CPU cooling

fan and a system cooling fan.

Figure 4-6: Fan Connector Locations

Page 36
