2 southbridge configuration, A300 motherboard, Page 124 – Intel iEi Motherboard A300 User Manual
Page 139
A300 Motherboard
CRT
EFP
LFP
CRT + EFP
CRT + LFP (Default)
Flat Panel Type [1280x1024 48bits ]
The Flat Panel Type BIOS option specifies the flat panel PC type being used.
NOTE:
Please refer to the technical documents that came with the flat panel PC to
ensure the correct settings are selected.
The following options are available:
640x480 LVDS (Default)
800x600 LVDS
1024x768 LVDS
24bits
1280x1024 LVDS
1400x1050 LVDS
1024x768 LVDS
18bits
1600x1200 LVDS
1280x1024 48bits
800x600 24bits
800x600 18bits
1024x768 36bits
6.5.2 SouthBridge Configuration
The SouthBridge Configuration menu (BIOS Menu 18) the southbridge chipset to be
configured.
Page 124
