Page 45
A300 Motherboard
Figure 4-2: Connector and Jumper Locations (Solder Side)
4.1.2 Peripheral Interface Connectors
Table 4-1 shows a list of the peripheral interface connectors on the A300. Detailed
descriptions of these connectors can be found below.
Connector
Type
Label
ATX power connector
20-pin connector
PW1
Page 30
