A300 Motherboard
PIN NO.
DESCRIPTION
1 Fan
Speed
Detect
2 +12V
3 GND
Table 4-6: System Fan Connector Pinouts
4.2.5 Front Panel Connector
CN Label:
CN5
CN Type:
10-pin header (2x5)
CN Location:
CN Pinouts:
The front panel connector connects to several external switches to control the front panel.
These switches control:
Front panel power
Backlight
Speaker
Figure 4-7: Front Panel Connector Location
Page 37
