A300 Motherboard

4.3.8 USB Combo Ports

CN Label:

USB1

CN Type:

USB Combo port

CN Location:

See Figure 4-20

CN Pinouts:

See Table 4-28

The two USB combo ports provide connectivity to USB devices. The USB port support

both USB 1.1 and USB 2.0.

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 USBVCC0

2 USBVCC1

3 D0-

4 D1-

5 D0+

6 D1+

7 USBGND0

8 USBGND1

Table 4-28: USB Connector Pinouts

4.3.9 VGA Connector

CN Label:

CN1.A

CN Type:

DB15

CN Location:

See Figure 4-20

CN Pinouts:

See Figure 4-26 and Table 4-29

The standard 15-pin female DB15 VGA connector connects to a CRT or LCD monitor

directly.

PIN DESCRIPTION PIN DESCRIPTION

1 RED

9 NC

2 GREEN

10

GROUND

3 BLUE

11

NC

Page 58
