Intel iEi Motherboard A300 - Manual (Page 160)

A300 Motherboard
Figure 7-13: GMA Driver Installation Complete
Step 5: The confirmation screen shown in Figure 7-13 allows user to restart the
computer immediately after the installation is complete or to restart the computer
later. For the settings to take effect the computer must be restarted. Once
decided when to restart the computer, click the “Finish” button. Step 0:
7.5 SATA - ALi RAID Driver Installation
CAUTION!
Because of the inherent limitations by Intel’s ICH4 chipset, the ALi M5283
SATA and RAID controller is implemented as a device that requires device
driver during the Windows installation process. To successfully install the
device driver, please carefully read the following instructions.
The ALi driver is especially required if SATA drives are the only hard disk drives in the
A300 system. Otherwise, the Windows installation program may fail to locate the hard
Page 145
