Model G0623X/G0623X3 (Mfg. Since 5/12)
-81-
sliding table parts list
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
301
P0623X0301
SLIDING TABLE SET 688 X 316
326
PN09M
HEX NUT M12-1.75
302
P0623X0302
T-SCREW M12-1.75 X 35
327
P0623X0327
ADJUST FOOT
303
PW06M
FLAT WASHER 12MM
328
P0623X0328
SWITCH MOUNTING BRACKET
304
PLW05M
LOCK WASHER 12MM
330
PS56M
PHLP HD SCR M4-.7 X 16
305
PN09M
HEX NUT M12-1.75
331
PCAP33M
CAP SCREW M5-.8 X 12
306
PLW03M
LOCK WASHER 6MM
332
P0623X0332
LOCATE PLATE
307
PN01M
HEX NUT M6-1
333
PN06M
HEX NUT M5-.8
308
PN13M
HEX NUT M16-2
334
PW02M
FLAT WASHER 5MM
309
PBHS11M
BUTTON HD CAP SCR M6-1 X 10
335
PLN05M
LOCK NUT M10-1.5
310
PBHS11M
BUTTON HD CAP SCR M6-1 X 10
336
PWF10M
FENDER WASHER 10MM
311
P0623X0311
LOCATE PLATE
337
PFN02M
FLANGE NUT M6-1
312
P0623X0312
LOCATE PLATE
338
PCAP33M
CAP SCREW M5-.8 X 12
313
P0623X0313
HANDLE
339
PW02M
FLAT WASHER 5MM
314
P0623X0314
LOCATE PLATE
340
PN06M
HEX NUT M5-.8
315
PCAP01M
CAP SCREW M6-1 X 16
341
PW03M
FLAT WASHER 6MM
316
P0623X0316
PIN LOCK
342
PLW03M
LOCK WASHER 6MM
317
PCAP115M
BUTTON HD CAP SCR M6-1 X 16
343
PN01M
HEX NUT M6-1
318
PBHS11M
BUTTON HD CAP SCR M6-1 X 10
344
P0623X0344
FLEXIBLE CONDUIT
319
P0623X0319
SLIDING TABLE END PLATE
345
P0623X0345
LOCATE PLATE
320
P0623X0320
SLIDING TABLE END PLATE
347
P0623X0347
MOTOR CORD 12G 4W
321
P0623X0321
LOCATE BLOCK
348
P0623X0348
PWR BOX CORD 12G 3W (G0623X)
322
P0623X0322
LOCATE PLATE
348
P0623X30348
PWR BOX CORD 12G 4W (G0623X3)
323
PLW04M
LOCK WASHER 8MM
349
P0623X0349
LIMIT SWITCH CORD 18G 2W
324
PCAP14M
CAP SCREW M8-1.25 X 20
350
P0623X0350
E-STOP CORD 18G 2W
325
P0623X0325
SUPPORT LEG
REF
PART #
DESCRIPTION
329V2
P0623X0329V2
MAG SWITCH NHD MS 1-18D V2.09.10
329V2-1 P0623X0329V2-1
SWITCH BOX NHD
329V2-2 P0623X0329V2-2
CONTACTOR NHD C-18D 230V
329V2-3 P0623X0329V2-3
OL RELAY NHD NTH-21 17-21A
329V2-4 P0623X0329V2-4
SWITCH BOX SCREW NHD
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
329A
P0623X30329A
MAG SWITCH MP-18 7.5HP 220V 3PH
346A
P0623X30346A
MAG SWITCH MP-18 7.5HP 440V 3PH
329-1A
P0623X30329-1A
SWITCH BOX
346-1A P0623X30346-1A SWITCH BOX
329-2A
P0623X30329-2A
CONTACTOR SDE MA-18 220V
346-2A P0623X30346-2A CONTACTOR SDE MA-18 440V
329-3A
P0623X30329-3A
RELAY SDE RA-30 18-26 20A
346-3A P0623X30346-3A RELAY SDE RA-20 8-12 10A
G0623X 5HP, 230V, 1-PH SWITCH
G0623X3 7.5HP, 220V, 3-PH SWITCH
G0623X3 7.5HP, 440V, 3-PH SWITCH
